567
All Wreckers
Equipment Overview
| Price | Contact for Price |
| Make | PETERBILT |
| Model | 567 |
| Year | 2024 |
| Stock # | 1001020145 |
| Location | Fullerton, CA |
Need Assistance?
(800) 222-4992Specifications
- A/C Condition: New
- Air Conditioning: Yes
- Axle: Tri
- Cab: Extended Cab
- Collisionmitigationsystem: No
- Color: White
- Cruise Control: Yes
- Differential Lock: Yes
- Drive: 8x4
- Driver Position: Left Hand Drive
- Dual Breathers: Yes
- Dual Exhuast: Yes
- Engine: CUMMINS
- Engine Brake: Yes
- Front Axle Lbs: 20000
- FrontaxlelbsUnit: Pound
- Fuel Type: Diesel
- Glider Kit: No
- Gross Vehicle Weight: 66000
- Gross Vehicle Weight Rating: Class 8
- GrossvehicleweightUnit: Pound
- Hassleeper: Yes
- Headache Rack: No
- Heated Mirror: Yes
- Horsepower: 565
- HorsepowerUnit: Horsepower
- Hours Meter Inaccurate: 0
- Lift Axle: Yes
- Lift Axle Type: Mid
- Mileage: 2918
- MileageUnit: Mile
- Navigation: No
- Num Speeds: 18 Spd
- Numberofbeds: 1
- Power Steering: Yes
- Power Windows: Both
- Ratio: 3.91
- Rear Axle Lbs: 46000
- RearaxlelbsUnit: Pound
- Rebuilttitle: No
- Sleeper: Flat Top Sleeper
- Sleeper Size: 44
- SleepersizeUnit: Inch
- Super Singles: No
- Suspension: Neway
- Tilt Telescope: Yes
- Tires: 11R 24.5
- Transmanufacturer: EATON-FULLER
- Transmission: Manual
- Turbo: Yes
- Wet Kit: No
- Wheel Base: 335
- WheelbaseUnit: Inch
- Wheels: Aluminum
General Description & Dealer Notes
ISX15 565 HP Fuller RTLO16918B 18 Speed. .Dana Spicer 22,000 lb, 4" in Drop, 23,000lb Front suspension.. 26" aluminum 70-& 80 Gallon Fuel Tank LH U/C, DEF Tank Small, Alum Cab 121in BBC Alum Hood SFFA, 10-3/4in Steel Rails 403-444in.Full Steel Inner Liner.Heavy-Duty Iron Front Spring Brackets Fwd & Rear.Dana Spicer 46,000 lb, Ratio 3.91 Rear Axle. Diff Lock Both Axles. SBM Valve. Synthetic Axle Lubricant All Axles. 52,000lb NUWAY Rear Air Suspension. Bendix AD-IS Air Dryer with Heater. Polished Alum Air Tanks Outside Frame Rails.Aluminum Space Saver Battery Box LH BOC.DPF Cab Entry Aluminum Non-Slip Step RH Under Cab. Heavy Duty External Tow Eye. /Platinum Interior. Intebrake (Furnished on Engine) Thermal Insulation Package in Cab.Thermal Insulation Pkg - 44" Low Roof Slpr. ( Platinum) Adjustable Steering Column - Tilt/Telescope,.Leather Steering Wheel..Rear Window Back of Sleeper Dark Tint, Power Lift Windows - Both Doors. Combo Fresh Air Heater/Air Conditioner.Sleeper Heater/Air Cond w/Controls in Sleeper. Cup Holder (Floor Mounted).Outside Sunvisor Stainless Steel. Aero Mirrors Ea Side Htd & Mtrzd 4-Way Adjustable. (4) Air Horns Rect-(2) 23in & (2) 26in. ConcertClass Audio System with CD. Bright Bezel Gauges ipo Black. Marker Lights (5) Bus LED Bullet. Fog Lights (2) Peterbilt. (1) 6in Spotlight Round Halogen LH. Switch on Dash for Light in Sleeper. 335" Wheelbase. Suspension Pressure Gauge. keyless entry. Air Ride Highback, Driver & Passenger. Premium Speaker Package - 6 speakers for cab. Air Disc brake package. Aluminum wheels. 385/65R 22.5s Fronts. Pusher 11R.22.5s. Rears BR 11R 24.5s. Winch brake. Tractor package.Smartway with Nav. Cab brackets for Strobe -Beacon... top of the cab. 5-year 350K Engine & Carb Warranty. 4 additional Switches.. removable Bug screen. Dual USB Ports. Smart sound insulation. 80,600 GVWR - _Century Model 9055T XL Boom Structural Rating (S.A.E.) Retracted 30� 100,000 lbs. 50 ton Maximum Angle 40� Maximum Hook Height (inches) 259" Reach Past Tailboard at 30� Boom Angle (inches) 125" BOOM SPECIFICATIONS - 9055 3-STAGE Boom Structural Rating (S.A.E.) Retracted 30� 100,000 lbs. Extended 18,000 lbs. Maximum Angle 39� Maximum Hook Height (inches) 299" Reach Past Tailboard at 30� Boom Angle (inches) 199" WINCH SPECIFICATIONS Winch Capacity (2) 50,000 lbs. Winch Type Planetary 2-Speed Cable Specifications 3/4" x 250' 6x37 I.W.R.C. UNDERLIFT SPECIFICATIONS Capacity Fully Extended to C.L. of Forks 17,000 lbs. @ 136" Capacity Fully Retracted to C.L. of Forks 55,000 lbs. @ 62" Underlift Tilt 10� + 7� - Tow Rating 80,000 lbs. OPTIONAL LOWRIDER UNDERLIFT SPECIFICATIONS Capacity Fully Extended to C.L. of Forks 18,000 lbs. @ 160" Capacity Fully Retracted to C.L. of Forks 55,000 lbs. @ 72" Underlift Tilt 10� + 7� - STANDARD BODY FEATURES 96" Wide Aluminum Modular Body Dual Control Stations Hydraulic Pressure Gauges (Drivers Side) Tailboard Recovery Anchors Tailboard Fork & Chain Storage Safety Chains in Rear Pockets 3 Large Forward Compartments Compartments Over the Wheel Well Push to Open/Push to Close Latches Power Toolbox Compartment Locks LED Federal Standard #108 Lighting Flexible Wire Loom LED Toolbox Lights Rubber Fenderettes Mud Flaps Chain Rack Fork Holders Recessed Air & Electrical Hook-Ups Adjustable Shelves Rubber Isolators Enclosed Inner Wheel Wells 3-Piece Light Pylon Aluminum Tread-Plate Walkway "D" Rings (Tailboard Mount) Power Touch System Includes 15-Function Wired and Wireless Controls, In-Cab Underlift Control, and Front & Rear Function Switch Panels STANDARD BOOM FEATURES Power Elevation Power Extension Dual Planetary Hydraulic Winches Air Cable Tensioners Air Free Spool Diagonal Rear Spades Flipper Foot Spades Dual Hydraulic Pump 360� Sheave Heads Cable Tie Backs Fork Riser Brackets STANDARD UNDERLIFT FEATURES Power Elevation Power Extension Power Tilt Hydraulic Fold 3-Stage Design 2 Piece Pivot Pin Upper/Lower Thrust Washer Handheld Lanyard Low Profile Crossbar 70� Pivoting Crossbar Low Profile Fork Holders 8 Pairs of Cast Steel Forks 1 Pair of Spring Lift Adapters 1 Pair of Hook Adapters. Body Serial # 90551F244321
204" CB Tri Axle (Century)
9055 Coach Low Rider (160” Reach)
Backlit Control Station
Hydraulic Extendable Rear Outriggers
Keypad and Wireless Remote (20 - 50 ton)
Pass Through Box (See Limitations)
auto: Crossover/Tunnel Box
Accessories
206” CA/180” CB - Dura Glow LED Strip Lights (Century)
auto: LED Strip Light Kit
25,000 Lb. Tire Lift (50-75 Ton)
38” Aluminum HD Tubular Pylon
6 3/4” Curved Fork
9055XL Stainless Tailboard Dress Up Kit
auto: Tailboard Dress Up Kit
A/C Inverter Kit (HD)
auto: Inverter Kit Install
Additional Chain Rack Weldment
Air Line Kit and Storage
Aluminum Tube Lighting Wing Kit
Angle Indicator
Bus Lift Storage System (Fold Down)
auto: Bus Lift Storage System
Color Control Handle Kit
Dual Hole Tie Down Kit
Dual Reverse Camera with Monitor
auto: Dual Camera System
Endless Loop Sling Kit
Evolution Snatch Block - 15 Ton
Fifth Wheel Plate (Requires Pintle 124002211)
Fork Risers
HD Chain Kit - Comprehensive
King Pin Attachment (requires 124002211)
King Pin Tow Plate Storage Bracket
King Pin Tow Plate/Trailer Recovery Loop
LED - Flex Lamp Rear Marker Lights (pair)
auto: Work Lights (Pair)
LED - Under Body Strip Light Kit(12V)
auto: LED Strip Light Kit
LED - Work Lights - Lower 70MM (Pair)
auto: Work Lights (Pair)
LED - Work Lights - Swivel 90MM (Pair)
auto: Work Lights (Pair)
LED - Work Lights - Underlift (Pair)
auto: Work Lights (Pair)
LED - Work Lights - Upper 90MM (Pair)
auto: Work Lights (Pair)
Ladder Kit, 12.5' Telescoping
Lift Axle Hub Kit
auto: Lift Axle Cover
MCI Bus Lift Eye Attachments (Pair)
Manual Override PTO (Single Action, HD)
auto: PTO Manual Override - HD
Muncie - Electric/Air PTO (6/8 Bolt, 50 Ton, HD)
auto: Electric / Air Shift PTO - HD, CC
Pintle Hook Attachment
Seamless Toolbox Matting - Yellow (HD)
auto: Toolbox Mat
Shackle Hanger Kit
Shackle Kit
Snatch Block Rack - Dual (2020)
auto: Snatch Block Storage Kit (Each)
Spacer Kit-Cast Fork
Stainless Steel Wheel Trim
auto: 8 * Stainless Fenderettes (Each)
Stainless Trim Kit - 4 Door (Century)
auto: Stainless Door Guard (Pair)
Tandem Axle High Hat w/Nut
auto: Axle Cover & Lugs (Single or Tandem)
Tool Cabinet - 7 Drawer With Removable Storage Tray
auto: Tool Cabinet Install
Tow Bar Light - 36" - Wireless
Trailer Ball Attachment (requires 124002211)
Trailer Converter Ball Kit
U Bolt Lift Attachments (Pair)
Underlift Tie Down Straps
Volvo Fork
Water Tank Kit
auto: Water Tank Kit
Whelen 10”x10” Lights w/o Brackets
auto: 2 * Strobe Light Kit (Mini or Whelen 10x10s)
Whelen M6 Light Kit - Body (Pair)
auto: LED / M6 Lights (Pair Body Mounted)
Whelen M6 Light Kit - Cab (Pair)
auto: M6 Lights (Pair Cab Mounted)
Whelen M6V Series Light Kit - Body (Pair)
auto: 4 * LED / M6 Lights (Pair Body Mounted)
Installation
7035 / 9055
Axle Cover & Lugs (Single or Tandem)
Bus Lift Storage System
Crossover/Tunnel Box
Dual Camera System
Electric / Air Shift PTO - HD, CC
Inverter Kit Install
LED / M6 Lights (Pair Body Mounted)
LED Strip Light Kit
Lift Axle Cover
M6 Lights (Pair Cab Mounted)
PTO Manual Override - HD
Snatch Block Storage Kit (Each)
Stainless Door Guard (Pair)
Stainless Fenderettes (Each)
Strobe Light Kit (Mini or Whelen 10x10s)
Tailboard Dress Up Kit
Tool Cabinet Install
Toolbox Mat
Water Tank Kit
Work Lights (Pair)
Paint
1 - Color Aluminum Body (9055 / V-100)
1 - Optional One Color Center Section (7035 - 9055)
Color Coded Sheave Heads
Paint Pylon
Standard Gloss Black Center Section
DAA
HD: Air-Weigh 4 axle Scale System, Tandem Axle, Bonus Purple
